로터리 스위치

(18919 결과)

로터리 스위치는 사람이나 기계적 상호 작용에 의해 샤프트가 회전할 때 전기 접점을 닫거나 열어 일련의 전기 연결을 만들거나 끊는 기계 장치입니다. 로터리 스위치는 위치 수, 데크 수, 데크당 극 수, 장착 유형, 접점 회로 구성, 투사 각도, 액추에이터 유형, 전류 및 전압 정격에 따라 선택됩니다. 일부 회전 스위치에는 조정 가능한 정지 장치가 포함되어 있거나 연속적으로 회전할 수 있습니다.

부분 #	제조업체	설명	유효성	가격
MRA112-BE Rotary Switches	NKK Switches	Switch Rotary SP12T 12 Knob Shaft PC Pins 0.25A 125VAC	재고	-
MRA112-BG Rotary Switches	NKK Switches	Switch Rotary SP12T 12 Knob Shaft PC Pins 0.25A 125VAC	재고	-
MRA112-CA Rotary Switches	NKK Switches	Switch Rotary SP11T 11 Knob Shaft PC Pins 0.25A 125VAC	재고	-
MRA206-CH Rotary Switches	NKK Switches	Switch Rotary DP6T 6 Knob Shaft PC Pins 0.25A 125VAC	재고	-
MRB12H-BE Rotary Switches	NKK Switches	Miniature PCB Process Sealed Rotary Switch; no positions: 2; index stops: Fixed; no decks: 1; no poles per deck: 1; Poles: SPDT; contact timing: Non-Shorting (BBM); Current Rating: 0.4VA (AC/DC); Rating (AC): 28V; Rating (DC): 28V; Actuator Type: Knob; actuator length: 14.30mm; angle of throw: 90?; contact material: Beryllium Copper; contact finish: Gold; Mounting Type: Panel Mount, Through Hole, Right Angle; Termination Style: PC Pin; Features: Sealed - Fully; depth behind panel: 12.56mm; Rating: 0.4	재고	-
MRB14B-A Rotary Switches	NKK Switches	Rotary Switch,	2024	-
MRT22-CB Rotary Switches	NKK Switches	Switch Rotary ON None ON DPDT 2 Knob Shaft Solder Lug 10A 125VAC 30VDC Miniature	재고	-
MRT23-BA Rotary Switches	NKK Switches	Switch Rotary ON OFF ON DPDT 3 Knob Shaft Solder Lug 5A 125VAC 30VDC Miniature	재고	-
MRT23-BC Rotary Switches	NKK Switches	Switch Rotary ON OFF ON DPDT 3 Knob Shaft Solder Lug 5A 125VAC 30VDC Miniature	재고	-
MRT23-BE Rotary Switches	NKK Switches	Switch Rotary ON OFF ON DPDT 3 Knob Shaft Solder Lug 5A 125VAC 30VDC Miniature	재고	-
MRT23-BF Rotary Switches	NKK Switches	Switch Rotary ON OFF ON DPDT 3 Knob Shaft Solder Lug 5A 125VAC 30VDC Miniature	재고	-
MRT23-BG Rotary Switches	NKK Switches	Switch Rotary ON OFF ON DPDT 3 Knob Shaft Solder Lug 5A 125VAC 30VDC Miniature	재고	-
MRT23-CA Rotary Switches	NKK Switches	Switch Rotary ON OFF ON DPDT 3 Knob Shaft Solder Lug 5A 125VAC 30VDC Miniature	재고	-
MRX108-BG Rotary Switches	NKK Switches	Switch Rotary SP8T 8 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
MRX108-BH Rotary Switches	NKK Switches	Switch Rotary SP8T 8 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
MRX108-CB Rotary Switches	NKK Switches	Switch Rotary SP8T 8 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
MRX204-CA Rotary Switches	NKK Switches	Rotary Switch, 4 Positions, DP4T, 1A, 30VDC, 9 PCB Hole Cnt, Solder Terminal, Rotary Shaft Actuator, Through Hole-straight,	재고	-
MRX204-CB Rotary Switches	NKK Switches	Switch Rotary DP4T 4 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
MRX204-CC Rotary Switches	NKK Switches	Switch Rotary DP4T 4 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
MRX204-CG Rotary Switches	NKK Switches	Switch Rotary DP4T 4 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
MRX204-CH Rotary Switches	NKK Switches	Rotary Switch, 4 Positions, DP4T, 1A, 30VDC, 9 PCB Hole Cnt, Solder Terminal, Rotary Shaft Actuator, Through Hole-straight,	2	-
MRX402-BB Rotary Switches	NKK Switches	Switch Rotary 4PDT 2 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
MRX402-BC Rotary Switches	NKK Switches	Switch Rotary 4PDT 2 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
MRX402-BH Rotary Switches	NKK Switches	Switch Rotary 4PDT 2 Knob Shaft PC Turret 2A 125VAC 30VDC Miniature	재고	-
PS1 Rotary Switches	NKK Switches	SWITCH ROTARY 2-11POS 30A 125V	56	-
